When you choose a Customized Zero Pollution Oil Free Scroll Air Compressor, DECHUAN delivers certified ISO Class 0 air purity. Ideal for medical and delicate manufacturing fields, this unit guarantees 100% oil-free performance. Get a quote!
Procuring from an experienced China Zero Pollution Oil Free Scroll Air Compressor factory allows global factories to meet strict sanitary guidelines. DECHUAN’s modular units completely eliminate hydrocarbons from the compression cycle, lowering lifecycle operating costs while protecting product integrity.
In high-purity industries like food packaging and pharmaceuticals, even a tiny trace of oil vapor can ruin large batches of product, damage brand reputations, and cause expensive downtime. The Zero Pollution Oil Free Scroll Air Compressor provides an absolute barrier against these risks:
Standard compressors use inline filtration to try and trap oil mist from the air stream, but these filters can fail over time. The Zero Pollution Compressor contains no oil to begin with, ensuring your air supply stays clean.
Because the system runs completely dry, the condensation drained from the air receiver contains no hydrocarbons, allowing you to discharge it safely without paying for specialized oil-separation treatments.
The certified oil-free air-end architecture ensures that the Zero Pollution Oil Free Scroll Air Compressor leaves no environmental footprint:
• Air Purity Certification: Certified 100% oil-free, zero-grade compressed air supply.
• Filtration Setup: Equipped with high-efficiency replaceable air inlet filters to capture airborne dust particles.
• Operating Pressure: Stable 8 barg and 10 barg configurations to meet strict industrial quality standards.
| Model | Max Pressure barg | Nominal Power kW | Air Flow m³/min | Weight kg | Noise Level dB(A) | Connection Size BSPT | Dimension (L×W×H) mm |
|---|---|---|---|---|---|---|---|
| W2i-A8 | 8 | 2.2 | 0.24 | 204 | 58 | 1/2" | 830 × 740 × 910 |
| W2i-A10 | 10 | 2.2 | 0.21 | 204 | 58 | 1/2" | 830 × 740 × 910 |
| W4i-A8 | 8 | 3.7 | 0.40 | 231 | 58 | 1/2" | 830 × 740 × 910 |
| W5i-A8 | 8 | 5.5 | 0.60 | 240 | 59 | 1" | 1445 × 800 × 1000 |
| W5i-A10 | 10 | 5.5 | 0.53 | 240 | 59 | 1" | 1445 × 800 × 1000 |
| W7i-A8 | 8 | 7.7 | 0.84 | 438 | 62 | 1" | 1445 × 800 × 1000 |
| W7i-A10 | 10 | 7.7 | 0.74 | 438 | 62 | 1" | 1445 × 800 × 1000 |
| W11i-A8 | 8 | 11 | 1.20 | 495 | 64 | 1" | 1445 × 800 × 1000 |
| W11i-A10 | 10 | 11 | 1.06 | 495 | 64 | 1" | 1445 × 800 × 1000 |
| W17i-A8 | 8 | 16.5 | 1.89 | 515 | 61 | R1 | 1280 × 770 × 1480 |
| W17i-A10 | 10 | 16.5 | 1.50 | 515 | 61 | R1 | 1280 × 770 × 1480 |
| W22i-A8 | 8 | 22 | 2.52 | 720 | 61 | R1 | 1330 × 880 × 1900 |
| W22i-A10 | 10 | 22 | 2.00 | 720 | 61 | R1 | 1330 × 880 × 1900 |
| W33i-A8 | 8 | 33 | 3.78 | 1000 | 63 | R1.5 | 1360 × 1030 × 1670 |
| W33i-A10 | 10 | 33 | 3.00 | 1000 | 63 | R1.5 | 1360 × 1030 × 1670 |
| Model | Nominal Power kW (hp) | Max Pressure barg (psig) | Capacity (FAD) m³/min (cfm) |
|---|---|---|---|
| R132n-110nVSD | 132-110 (175-150) | 4.5-10.0 (65-145) | 18.1-21.9 (646-772) |
| R90ne-160neVSD | 90-160 (125-200) | 4.5-10.0 (65-145) | 13.0-30.0 (313-1060) |
1. 100% Lubricant-Free Chamber: The scroll wraps operate without any fluid injection. This means the air compressor cannot introduce oil mist into your production air lines.
2. Eco-Friendly Zero Emissions: Our design actively supports modern corporate carbon-neutral goals by producing zero hazardous oil sludge waste, eliminating the need for expensive oil disposal services.
3. Smart Microprocessor Care: Monitors exhaust pressure and key operational parameters in real time. If any temperature abnormality is detected, the compressor shuts down automatically to prevent hardware damage.
Every Zero Pollution Oil Free Scroll Air Compressor undergoes a multi-point inspection process before leaving our Shanghai assembly facility:
• Spectrometric Air Testing: The discharge air is analyzed using high-sensitivity sensors to confirm the complete absence of trace volatile organic compounds (VOCs).
• Electronic Overload Calibration: Smart starters and temperature sensors are pre-set and tested to ensure the machine shuts down safely if an operating variance is detected.
• Continuous Pressure Run: Units are run under full load for several hours to guarantee stable operating parameters before being approved for export.
A: No, an oil-free compressor still draws in ambient humidity from the air. To remove water vapor, make sure your downstream refrigerated air dryer or desiccant system is turned on and operating properly.
A: Yes, an integrated running timer comes standard, allowing your maintenance team to easily track operating hours and plan routine filter replacements.
A: We recommend a quick visual check once a week to ensure the drain screen isn't blocked by ambient dust particles, allowing moisture to clear freely from the system.
